Gewiss 16a 110V 2P+ E Plug IP44 Commando Industrial Plug

Click to enlarge

Gewiss 16a 110V 2P+ E Plug IP44 Commando Industrial Plug

Brand: Gewiss

Product Code: GW60001H

  • STRAIGHT PLUG HP
  • IP44/IP54
  • 2P+E 16A 100-130V 50/60HZ
  • YELLOW
  • 3 PIN
  • 4H
  • SCREW WIRING

Available stock: 8


£ 4.92 incl VAT
Unit:

16A 110V Commando Plug Yellow 3 Pin Trailing / Straight

Gewiss GW60001H

  • Colour: Yellow
  • Rated current : 16amp plug
  • 3 PIN
  • IP degree: IP44/IP54
  • No. of poles: 2P+E
  • Mechanical resistance: IK09
  • Reference h: 4
  • Type: Straight plug
  • Rated voltage: 100 - 130 V
  • Frequency: 50/60 Hz
  • Terminal tightening capacity: 1-2.5mm2 flexible cables - 1.5-4mm2 rigid cables
  • Cable clamp tightening capacity: 7.5-13.8 mm
  • Operating temperature: -25 +55 oC
  • Type of wiring: With screw
  • Type of material: Halogen-free in compliance with EN 60754-2
  • Electrocod: 2230
  • Glow wire test: 850 oC (active parts) - 650 oC (passive parts)
  • Total number of operations: > 5000
  • Permissible overload: 22 A
  • Breaking capacity at 1.1 Un: 20 A
  • Insulation resistance: > 10 M
  • Thermo-pressure with ball: 125 oC (active parts) - 80 oC (passive parts)

GW60001H Data Sheet - PDF
