Gewiss 32a 240V 2P + E 90deg Wall Mounted Appliance Inlet IP67

Click to enlarge

Gewiss 32a 240V 2P + E 90deg Wall Mounted Appliance Inlet IP67

Brand: Gewiss

Product Code: GW60437

  • 90o ANGLED SURFACE MOUNTING INLET
  • IP44
  • 2P+E 16A 200-250V 50/60HZ
  • BLUE
  • 3 PIN PLUG
  • 6H
  • SCREW WIRING

Available stock: 5


£ 19.45 incl VAT
Unit:

16Amp 240v Commando Plug Blue 3 Pin Wall Mounted Plug / Inlet


  • Product Code: GW60404
  • Colour: Blue
  • Rated current: 16amp plug
  • 3 Pin Plug
  • IP degree: IP44
  • No. of poles: 2P+E
  • Mechanical resistance: IK08
  • Reference h: 6
  • Type: 90o angled surface mounting inlet
  • Rated voltage: 200-250 V
  • Frequency: 50/60 Hz
  • Terminal tightening capacity: 1-2.5mm2 flexible cables - 1.5-4mm2 rigid cables
  • Cable clamp tightening capacity: 7.5-13.8 mm
  • Operating temperature: -25 +55 oC
  • Type of wiring: With screw
  • Electrocod: 2230
  • Glow wire test: 850 oC (active parts) - 650 oC (passive parts)
  • Total number of operations: > 5000
  • Permissible overload: 22 A
  • Breaking capacity at 1.1 Un: 20 A
  • Insulation resistance: > 10 M
  • Thermo-pressure with ball: 125 oC (active parts) - 80 oC (passive parts)


GW60404 Data Sheet - PDF
