Gewiss 32a 240V 2P + E Plug IP44/IP54 Commando Industrial Plug

Click to enlarge

Gewiss 32a 240V 2P + E Plug IP44/IP54 Commando Industrial Plug

Brand: Gewiss

Product Code: GW60015H

  • STRAIGHT PLUG HP
  • IP44/IP54
  • 2P+E 32Amp 200-250V 50/60HZ
  • BLUE
  • 3 PIN PLUG
  • 6H
  • SCREW WIRING

Available stock: 1


£ 9.90 incl VAT
Unit:

32Amp 240v Commando Plug Blue 3 Pin Trailing / Straight

  • Colour: Blue
  • Rated current: 32amp plug
  • 3 Pin Plug
  • IP degree - IP44/IP54
  • No. of poles: 2P+E
  • Mechanical resistance: IK09
  • Reference h: 6
  • Rated voltage: 200-250 V
  • Type: Straight plug
  • Frequency: 50/60 Hz
  • Terminal tightening capacity: 2.5mm-6mm2 flexible cables - 2.5-10mm2 rigid cables
  • Cable clamp tightening capacity: 9.2-19.9 mm
  • Operating temperature: -25 +55 oC
  • Type of wiring: With spring
  • Type of material: Halogen-free in compliance with EN 60754-2
  • Electrocod: 2230
  • Glow wire test: 850 oC (active parts) - 650 oC (passive parts)
  • Total number of operations: > 2000
  • Permissible overload: 42 A
  • Breaking capacity at 1.1 Un: 40 A
  • Insulation resistance: > 10 M
  • Thermo-pressure with ball: 125 oC (active parts) - 80 oC (passive parts)


GW60015H Data Sheet - PDF
